供应分纸压线机

上海齐盛包装机械厂

SBF系列薄刀分纸压线机SBF Series Thin-blade Separating and Trace Pressing Machine主要用来纸板的分纸和压线。Mark of main Yong Lai cardboard paper and line ball.特点Features:该机采用无极调速电机为动力，齿轮链轮同步传动，具有燥声低，传动平稳，调节范围方便等特点，分纸刀采用1.2mm的高强度合金材料制成，输送辊采用胶辊装置，确保无痕，分切正确，切率小省电。并装有自动、手动磨刀装置，从而使纸板切口光整平滑，瓦楞不压瘪。是目前纸箱包装行业提高产品质量的首先设备。The machine is driven by stepless motor and its power is transmitted synchronically with gears and sprocket wheels. It is featured with low noise, smooth drive and easy adjustment of breadth. The paper separating blade is made of 1.2mm high-strength alloy and feeding rollers are made of rubber that leave no marks on paper. The machine is error-free in paper separating and good at saving electricity with lower power rate. Equipped with auto and manual blade milling unit, the machine can ensure smooth edges of the paper and non shrunken corrugations and is recognized as the ideal equipment for carbon box and packing industries.主要技术参数Main technological parameters型号（单位：mm）Model（Unit：mm）SBF2200门幅Breadth2200大进纸尺寸Maximum feeding size2000小分纸尺寸Minimum separating size120刀片直径大Maximum blade diameterφ260刀片直径小Minimum blade diameterφ225电机功率Motor power rate3KW压线轮（组）Trace pssing wheels(set)4压线轮小宽度60MM分纸刀（把）Paper separating blades(piece)3分纸刀小宽度180MM机械速度无级调速重量（kg）Weight(ton)2000外形尺寸长*宽*高Overall dimensions L*W*H3050*1400*1350 导购推荐 加工定制 是 品牌 QISHENG 型号 SBF 产品用途 分纸 压线 产品别名 分压机 属性 属性值
